In Size 2 only
The NITRO® rehabilitation chair is designed to deliver exceptional comfort and support for individuals undergoing rehabilitation. Its advanced design and wide range of adjustable features allow for precise customization to meet each user’s specific needs.
Backrest Height and Angle Adjustment
The NITRO® chair offers smooth, stepless adjustment of both the backrest height and angle. This allows for precise positioning tailored to the user’s preferences and medical requirements.
Seat Depth, Height, and Tilt Adjustment
Seat height can be easily adjusted by extending the legs, with each leg adjustable independently to enable a tilted, ergonomic bucket-style seating position. The seat also features smooth, stepless depth adjustment to ensure a comfortable and ergonomic fit.
Adjustable Footrest
The footrest features both height and angle adjustment, enabling optimal leg positioning. Adjustable feet enhance stability and provide proper support for the user’s feet.
The NITRO® rehabilitation chair is a versatile and supportive solution throughout the rehabilitation process. Thanks to its extensive adjustability, it can be tailored to individual needs, contributing to a more effective and comfortable rehabilitation process.
STANDARD EQUIPMENT
· Frame with height adjustment,
· Backrest with smooth and stepless height adjustment and tilt angle adjustment,
· Seat with smooth and stepless depth adjustment,
· Pelvic belt,
· Tilt-in-space function,
· Detachable footrest with smooth and stepless height adjustment, extension adjustment and tilt angle adjustment,
· Footplates with spacing, extension and tilt angle adjustment,
· Foot stabilizing straps,
· Upholstery MEDICUS™: MED SEA / MED GREY / MED SKIN / MED RED (1).
Sizing
Symbol | Description | Unit | Size 1**** | Size 2 | Size 3**** | ||
---|---|---|---|---|---|---|---|
FH | indicative user height* | [cm] | 100 – 120 | 110 – 150 | 150 – 180 | ||
t | seat width | [cm] | 31 | 38 | 45 | ||
BK | seat depth | [cm] | 26 – 34 | 30 – 40 | 35 – 45 | ||
s | backrest width | [cm] | 32 | 39 | 46 | ||
h | backrest height | [cm] | 42 – 52 | 49 – 61 | 55 – 70 | ||
FK | footrest length | [cm] | 25 – 35 | 29 – 43 | 34 – 50 | ||
default footers size** | [cm] | 0 | 1 | 2 | |||
FF | distance between the center of the footers | [cm] | 15 – 26 | 16 – 33 | 17 – 40 | ||
k | seat height | [cm] | 32 – 40 | 39 – 51 | 43 – 57 | ||
α1 (alfa1) | backrest tilt angle | [°] | 90 – 140 | 90 – 140 | 90 – 140 | ||
α2 (alfa2) | seat tilt angle*** | [°] | 0 – 15 | 0 – 18 | 0 – 20 | ||
α3 (alfa3) | footrest tilt angle | [°] | 115 – 165 | 115 – 165 | 115 – 165 | ||
max. user weight | [kg] | 65 | 80 | 120 |
